2.54 mm pitch connector mini jumper black / white / blue / yellow / red / green

Product Categories

WCON ELECTRONICS ( GUANGDONG) CO., LTD

Contact Now

Name: 254 mm pitch connector mini jumper black white blue yellow red green
Brand: WCON
Price: 1 USD

Brand Name : WCON

Model Number : 3710/20/30-XX01XS0X01

Certification : UL/SGS/ROHS/CUL

Place of Origin : Dongguan, Guangdong, China.

MOQ : 20000pcs

Price : Negotiable. It depends on the customers' requests.

Payment Terms : T/T

Supply Ability : 800000kpcs

Delivery Time : 15-25 Days

Packaging Details : Bag Package

Plastic Height : 4.5/6//6.5/8.5/13.5mm

Housing Shape : Open/Close

Contact Plating : Gold Flash on Contact, Tin on Tail

Plastic Material : Polyester

Color : black(Standard)

Pitch : 2.54mm

Key Words : 2.54 mm pitch connector mini jumper

Contact Now

mini jumper 2.54mm close type PBT black brass bag packing wcon connector.

Products Issues	Products Descriptions
Products Characteristics	Mainly in electronic products and electrical equipment to provide convenient electrical plug-in connection, widely used in electronic equipment so that the production of electronic products and maintenance efficiency can be greatly improved.
Products Specifications	Current Rating	3.0AMP
	Contact Resistance	20 Milliohm Max
	Insulation Resistance	1000 Milliohm Min
	Withstand Voltage	1000V AC/Minute
	Operation Temperature	-40℃ to + 105℃
	Contact Material	Brass
	Contact Plating	Au or Sn Over Ni
	Insulator Material	Polyester(UL94V-0)
	Standard	PBT Black+30%GF
Products Applications	Mainly used in electric power system, communication network, financial manufacturing, elevator, industrial automation, medical equipment, office equipment, home appliances, military manufacturing and other industries.

2.54 mm pitch connector mini jumper black / white / blue / yellow / red / green
